Solar MD SS4083 8.3kWh Wall Mount Lithium Battery

The Solar MD SS4083 8.3kWh wall mount lithium battery uses lithium iron phosphate cells for its streamlined energy storage. The flexible modular design enables it to be set up with multiple batteries. Capacity can be increased through a parallel connection of the batteries. Grid tied, off-grid and hybrid inverter and charger systems Residential and commercial UPS systems.

FEATURES:

• Stable discharge platform
• Excellent safety
• Long life cycle
• High temperature performance
• High energy density
• High charge and discharge rate
• High efficiency
• No pollution

Applications:

• Grid tied, off-grid and hybrid inverter and charger systems
• Residential and commercial UPS systems

Technical Specifications:

• Cell Chemistry: Lithium Iron Phosphate (LiFePO4)
• Cell Manufacturer: CALB
• Rated Capacity: 8.3 kWh
• Nominal Power: 7.5 kW
• Usable Battery Energy @ 0: 3C 7.51kWh
• Nominal Voltage: 51.2
• Weight: 70KG
• Communication CANBUS/R485)
• Dimensions (W x D x H): 389 x 183 x 635 mm
• Cycle Life @25°C: ≥ 4000
• Charging Efficiency: 99%
• Transport: UN3480 & UN38.3
• Operational temperature: 0°C to +50°C
• Storage Duration : 6 months @25°C
• Safety Standard Compliance: IEC 62619 / UN38.3 / UL1642
• Cell Certificate: TUV / CE / RCM / UL1642
